Professional Meat Mincer Supplier Industrial Fresh Frozen Meat Grinder with High Capacity
Product Description:
This Meat Mincer Supplier Industrial Fresh Frozen Meat Grinder provides efficient solutions for various production needs with its excellent versatility and wide applicability. It not only has a powerful function of mincing frozen meat, but also can complete the mincing process in a short time while maintaining low temperature, effectively ensuring the freshness and quality of food. In addition, its unique forward and reverse functions completely eliminate the possibility of blockage in the meat grinder, greatly improving the convenience and efficiency of operation. The design of multiple orifice plate combinations meets the personalized needs of different meat products, making production more flexible and versatile. This device not only saves time and effort, but also achieves preservation and quality, making it an ideal choice for the meat processing industry.
Technical Parameters:
| Model | Production capacity (kg/h) | Power (kw) | Blade diameter (mm) | Dimensions (mm) | Weight (kg) |
| SJR-D100 | 200-500 | 4 | 100 | 900*600*1010 | 260 |
| SJR-D120 | 300-800 | 7.5 | 120 | 1150*700*1100 | 300 |
| SJR-D130 | 500-1200 | 11 | 130 | 1180*760*1140 | 600 |
| SJR-D160 | 800-2000 | 15 | 160 | 1400*850*1270 | 800 |
| SJR-D200 | 1000-3000 | 22 | 200 | 1700*1400*1600 | 1200 |
| SJR-D250 | 1500-5000 | 37 | 250 | 1800*1500*1600 | 1400 |
| SJR-D300 | 1500-6000 | 55 | 300 | 1900*1500*1800 | 1800 |
Product Features:
Energy-saving, durable, convenient and efficient, it features a compact structure, attractive appearance,
simple operation, low power consumption, easy cleaning and maintenance, as well as safety and hygiene.
The meat grinder head and components in contact with food are made of high-grade stainless steel, ensuring safety and no pollution.
The shell has a smooth line, without crevices for dirt accumulation or sharp edges that could cause harm, making it easy to clean.
Performance:
1: It adopts fully enclosed gear transmission, with a compact structure, smooth operation, reliable performance, and convenient maintenance.
2: The lines are smooth, easy to clean, and elegant and beautiful.
3: Energy-saving, durable, convenient, fast, and hygienic.
Application:
The multi-functional meat grinder is suitable for various frozen and fresh meats, chicken and duck carcasses, pork rinds, beef hides, fruits, and vegetables. The machine primarily operates by using a rotating screw to push raw materials from the hopper to the pre-cut perforated plate. The rotating cutting blades and the cutting edges formed by the holes in the plate work together to shear and cut the raw materials. By configuring appropriate blades and perforated plates according to material properties and processing requirements, this machine can produce particles of varying sizes to meet downstream process specifications. Performance Features: Multi-functional meat grinder, excellent versatility, wide applicability, high production efficiency. Hourly capacity ranges from 500 to 3,000 kg/h.
User Operation Requirements
1, Check that the power supply voltage meets the requirements, the power supply wiring should be firm and reliable, and the body should be reliably grounded.
2, Remove the meat grinder assembly, wash it with water, and then install it in sequence and lock the handle.
3, Pour in the pre-cut pieces of meat and turn on the machine.
4, After use, immediately disassemble the meat grinder assembly and clean it to avoid bacterial growth.
5, Do not feed material by hand.
